As a consequence of moving, I started looking through some of the thousands of 35mm transparencies I have taken over the years. Sadly many of them have deteriorated horribly. This has prompted me to scan the whole lot in an attempt to preserve them before they are lost altogether.
These were mostly taken with the Praktica Nova B prior to 1989, then with the first of a couple of Pentax K1000s. The earliest film stock was Agfa CT18, a long discontinued 50ASA colour reversal film, they have survived well, but those taken with Agfa CT100 (100ASA stock) have fared very poorly. At left is a 1930s Pou Du Ciel, the infamous "flying Flea", this example being photographed in September 1985 and as you can see the colours have faded completely, despite being stored in a closed filing system.
So the main activity at the moment is restoring photographs, a mind numbingly tedious and time consuming task it is too! Every slide is given a thorough dust off and then scanned. No two slides have faded in the same way, it entirely depends on the colours in the slide and how far it was into the storage system, those closer to the front faring worst. Restoration involves digitally editing the colour channels of the slide until it looks about right.
Here is the same slide after restoration.
Thanks go to M. Pendrith and an anonymous donor called "someone" who have made donations to the film fund recently. I currently have earmarked this for a colour 120 through the Agiflex, a colour film through the Praktica VF (a bit of a gamble that one!) and processing for a film through the Paxette.
Owing to the ongoing slide restoration project, I only have a film in the Korelle B at the moment.
With absolutely no fanfare whatsoever, the website completed 20 years online. After all this time it's remained much the same stylistically, deliberately so. For those who weren't here at the start, the maroon background is inspired by the often red bellows of cameras in the early part of the 20th century and in particular my Grandmother's Butchers Cameo, which serves as the back button. The typeface changed from a serif font (Palatino) to a sans serif a few years back, but the colour remains the same, inspired by the brass of the early cameras. More recently the history pages were removed, as there are better sources for that information and the Collections Room introduced, which is significantly better. These pages group the cameras in to types, say 35mm SLRs. Every camera has a back link to its relevant collection page allowing casual viewers to explore similar types. The Era rooms remain a popular route through the site as they give a very graphic insight to styling trends over eighty years. Interestingly the Covid19 pandemic coincided with a marked change in focus, prior to the lock downs the 1920s and 1930s were by far the most popular pages but a shift has taken place this last eighteen months and now the 1950s and 60s are the most popular.
The project pages remain popular and the recent Rolleiflex resurrection now tops the other pages, but interest in the KW Pilot is all but non existent, no doubt a reflection its properties as a camera.
My recent move has been completed and the cameras are all out of storage once again and have new display cabinets to live in. Deciding how was a tricky decision, the website is so much more flexible in that respect. Also complicated by the maximum shelf loading of 22kg. As yet I haven't been able to make a serviceable dark room, but can process films once again. Only two cameras are loaded right now, the Reflex Korelle B and the Agilux Agiflex.
Anyway thank you for being one of a select band of two million (ish) viewers over the past 20 years, may you find something to interest you here today.
Major changes! I am moving... all the cameras have been meticulously boxed up, reunited with their original leather carrying cases where I have them and are currently in store. The darkroom has been removed, boxes of developing tanks etc etc. Sadly I had to cull three enlargers. I took the opportunity to test fire every camera as it came out of the cabinet, to reveal a large number had died - such is the fate of many not regularly used cameras. On a positive note, the Praktisix was rebuilt in germany and has been returned, but is now in store. Hopefully when things have settled down I may get a chance to use it. I've lost track of which cameras are loaded at the moment, but I did finish a roll in the Agifold but haven't been able to process that as yet. The Agiflex is loaded, as is the Sputnik and Paxette, and possibly one or two others. Right now I am up to my neck in it, so little going on with the cameras for now.
The first test film through the KW Pilot Super was developed and a handful of results posted. Well I'm not convinced that the Pilot deserves the "Super" it acquired when developed from the Pilot 6. As suspected - the weight of the glass mirror, shutter tray and rotational mass of the speed selector makes holding the thing still enough all but impossible. From my perspective I was happy enough that the shutter actually worked in a sensible manner and that the speeds suggested by my method for timing shutters held good for this one too. The camera is mechanically as good as it was ever likely to be, the lens less so, eighty years of use and abuse have done it few favours - but the Laack Pololyt wasn't anything special before the scratches eroded whatever quality it once had. Even so it's fun to use, and will see a bit of use yet.
Re-acquaintance with old Travel Companions.
With the major restorations out of the way it's time to start the rolling maintenance tasks. This Gomz Sputnik missed out on a deep clean as it was acquired in the Old Arbat Street market in Moscow during July 2003. It was pressed into service there and then. After seven years being carted around the globe it worked it's way to the back of the camera drawer and sat there still loaded but unused. The last film from it was showing signs of uneven exposure within the stereo pairs, with the left hand side rather overexposed. It finally went into the workshop this week. The problem was the slave shutter opening early, giving a longer exposure. The focus was very stiff with dried grease, so that was all cleaned out and greased again. A thorough clean and focus adjustment, sees it ready for a test film again.
Also the Praktisix has worked to the head of the queue. Some years ago it was tasked to take a photograph using the built in timed release. This jammed the shutter, the mirror wouldn't release and the camera was put aside in the display cabinet for another day. That was around 2005. I had it out of the cabinet recently to see if I could get it working and with some cajoling the first curtain released, but the mirror remained jammed. The second curtain was stuck and when I did get it moving, the tell tale wrinkles from becoming stiff were all too evident. The lens has also dried out and is solid. As this camera is quite complex I have elected to send it to Germany to be repaired, leaving on 1st Feb. and the gentleman in Germany informed me it arrived safely on 5th. In due course I will write up my experience in project 13, tempting fate?
Pampering a Pulverized Pilot.
Seen here is the KW Pilot Super that was acquired a few months back in a job lot of fetid photographic relics. This has entered the workshop for the initial survey, consuming much thought as it has been modified very early in its career. Initially I thought it was just the addition of a flash socket, but I am beginning to think it was for something else. All the components used in the modification are fairly heavy duty and would appear to come from aviation stores. Whoever did the the work was skilled, but it doesn't look like the work of a photographic technician. The remains of the marking out can still be seen, as is the number 4, which hints that there are at least three others. The marking out of the holes to be cut and new holes drilled and tapped suggests that what had to be done was planned in advance, rather than a one off ad hoc conversion. A great deal of effort was expended that entailed dismantling the entire camera. A neat rectangular hole was made and a relay contact arranged to connect when the mirror reached the top of its travel, a corresponding copper contact was riveted to the mirror platten, suggesting that a decent current was expected to flow. This would have created a considerable amount of swarf, but not a trace has been found, confirming that the camera was totally dismantled when this work was done. At the end of the exposure, the circuit remained live, no attempt has been made to break it when, say, the second blind reaches the end of it's travel. It may have been used as a sequence camera, each one triggering the solenoid of the next in sequence, or it may have been a remote camera that lit up a bulb on a control board to let the operator know that camera number 4 had tripped. It could have been used for flash too, with the proviso that the shutter be cocked before connecting the flash, otherwise it would go off instantly you connected it. When this work was carried out the depth of field and extinction meter data plate that was riveted to one side was removed and the rivets hammered flat, the extinction meter was also deleted and the holes neatly disguised. From the wear, it saw considerable use in this form.
After some thought I have decided to retain the modifications in this case, although the option to return it to stock remains should an extinction meter show up. So for now the intention is to restore it to the condition it appears to have spent its working life. Now completed and can be seen in Project 12.
The first thanks for 2021 go to Mr. C Flynn for his donation to the film fund. Technically this arrived at the tail end of last year, but I'd already closed the December news page by then.
Revolting Rolleiflex rescue.
The focus of our attention this month is the rescue of the rotting Old Standard Rolleiflex, documented in Project 11. Being able to spend this amount of time was brought about by our enforced Covid19 lock down here in the UK. Good progress has been made as shown in the newly painted die cast zinc shell seen here after having the Rolleiflex logo painted back in and the second coat of lacquer being allowed to harden off for a few days. The mirror came back from being re silvered and there just remains the parts that are being re nickel plated to be returned from the plater's until all the restored sub assemblies can come together once more.
You can see the progress in Project 11.
It was subsequently finished off and a test film has gone through it already, some of the results can be seen here.
20th anniversary clean
This Ilford Advocate joined the collection in December 2000 and has always been a favourite. It was last out and about in 2008 and was about to be taken out again but I decided it had become a little dusty. The display cabinet is not exactly air tight and dust is drawn in every time it's opened and closed. So it's currently on the bench having a deep clean and service, so far nothing found to be wrong, just the focus helix grease is a little dry, the viewing optics cloudy and things felt a little slack. Checking around I noted that the Science Museum website notes that the casting material is unknown. So I dismantled the camera from the rear casting and removed all fittings. By displacement I gained a 7mm rise in a parallel plastic bottle with internal diameter 80mm, to give a volume of 32.672 cubic centimetres. With such small a volume and the meniscus to deal with, there's likely a bit of error in there. The weight was 85.5g on a calibrated digital scale. This gives an average material density for the rear casting with its enamel finish of 2.62g/cm3. Pure aluminium would be 2.6. The only logical choice of casting metal would be one of the die casting aluminium alloys, typically in the 2.7 range. Given the method to obtain the volume this is well inside the expected error and there are no metals in this density range that would be more likely used. The camera has since been re assembled
Also into the workshop went the Rollei 35S. This fabulous little camera was suffering from a cloudy viewer, so had its lid whipped off and the viewfinder optics given a spruce up. A bit of historic damp had eaten away the wiring to the light meter too, so that was repaired, but the battery is long dead, so it will still be used as a manual next time it ventures out.
Thanks go to Mr. M. Teadham this month for a donation to the film fund. Thank you very much. As yet, not allocated, but I suspect that half of it will go on some rapid fixer as I am down to my last half bottle.
Well that's 2020 done. Not your average year. Stay well and safe everyone, a few more months will see us through.
Tales of terrible tamperings and rivet rot.
Winter has arrived along with further Covid19 restrictions in the UK, so I bought a box of the nastiest most rotten wrecks some ebay seller ever offered to keep me amused. The one that seduced me most was a KW Pilot Super, a camera that has been on the hit list for a while. There's also an early "Old standard" Rolleiflex and a Zeiss 520 Ikonta A, both worth saving. A bonus was a Halina A1 which donated it's nameplate to our example and a very tatty Box Tengor, which will be disposed of.
The Halina was robbed for parts then combined with spares from the parts bin to produce a Frankenstein edition, now on Ebay!
First into the workshop is the Ikonta, seen here. Now this poor old thing (as per the others) has suffered appallingly, but the Ikonta A is the cutest of the breed, and it makes a change to have the Derval shutter, as nice as the Compur shutters are mechanically, the Derval is prettier. The Ikonta has severe rivet rot. I invented this term for the Kodaks of the 1920s that rot around the rivet heads, the different metal of the rivet causes a small electric current where it passes through the aluminium back, any moisture present completes all that is needed for accelerated oxidation. You will see this as bubbling under the leatherette covering. However Zeiss cameras suffer from it spontaneously, rather than just around the rivet heads.
Unchecked, this will eventually eat right through the aluminium. Things hadn't quite got that advanced with this one, but the pits were about quarter of the way through when I removed the covering. The Derval shutter has been overhauled, during which I discovered some terrible tamperings, at some point someone lost the detent spring and associated ball bearing, and inserted a crude bit of rod instead. Ugh. Amazingly, at the bottom of my tub of bits I found a spring and a ball that fitted. It's now a happy Derval. The rest of the camera is being de-wreckified as the lock down continues.
Thank you to Mr. J. Henry (again) and Mr. B. Hermansson for their donation via Buy Me a Film this month. This has been used to buy ten rolls of Foma 120.
The Rolleiflex and the Pilot Super are even worse. The Rolleiflex is so bad, a project page has been created for it. This will be updated as it progresses, as it's likely to be a fairly protracted effort.
Here it is when it arrived, really it's beyond saving, but we are in Covid19 lock down so it will give me something to do. The right hand image shows the shutter speed and aperture setting window as it was being dismantled.
First off, thanks to Mr. M, Teadham and Mr. J. Henry who made donations via the film donation links this month. This has been used to process two colour films for the Agiflex, out of the 24 frames, 23 came out, one I simply forget to shoot. Not all are worth publishing, but I have thinned them down aggressively for the results page. But here's one showing one of my favourite local sites.
Given that the Agiflex was dead on arrival and needed a total strip and new shutter, the camera has settled down nicely to be a reliable performer.
A new arrival this month is another Agilux camera in the form of an Agilux Agifold, this being the first rangefinder version c1950. Cosmetically it was fine as it was but the Agilux shutter was sick. A good clean sorted it out, but it did take a while as it had some surface rust on the various levers and cams. It's not ready for using yet as the rangefinder needs adjustment and the focus checked as all the lens elements were separated during cleaning, but a page has been started for it along with the usual 360 degree view.
A first outing with my homemade telephoto lens for the Ruby Reflex Special was an abject failure. The plates picked up some contamination whilst stored in a transit bag and came out with large blobs all over them. Also revealed was a failed velvet light stop on one of the two "serviceable" plate carriers and some nasty reflections inside the homemade lens barrel which bathed the entire plate in scattered light, this is due to the use of a parallel tube - driven by lack of availability of anything else and simply not enough room. Back to the drawing board for that one, but one image showed promise and I think I can probably insert a light baffle to solve the reflections.
Some new images taken with the Braun Paxette have been added to the gallery for it, also a gallery for the Brownie F has been created, The Thornton Pickard Reflex has been out and about too, although no additional images added for it. The Agiflex I was completed and now has a gallery too. The Agiflex restoration was partly documented in Project 9 and my unorthodox method of setting up shutters was finally confessed in Project 10.
Back in the UK finally after managing to get a flight during COVID-19 restrictions. I processed a couple of films from the Brownie F, and a disappointing set for one of the Ikontas. A telephoto lens was built for the Thornton Pickard Reflex, just for the shear fun of it. Yet to take it out for an outing. It's a 305mm lens with way more coverage than needed for quarter plate, but it was sulking in the bag of bits, so I thought I'd give it a shot. May make an interesting portrait lens. Or be a CWOT... a Complete Waste Of Time. The workshop was overrun by the Agilux Agiflex I which put up a real fight during the deep clean and overhaul. I wound up putting new curtains in it, but it proved to be an awkward customer. Anyway it all seemed to come together in the end and responded well to my unorthodox method of setting the shutter up. It currently has a test film in it, so the proof will be in the pictures I guess. The Reflex Korelle B also went back into the workshop to sort out the shutter curtain timing as that wasn't quite right from it's rebuild in 2017. Sadly the Williamson Aerial camera died. I took it out for an outing and it jammed horribly when I set it to 400th/sec, Upon getting it apart, the mainspring had failed, distorting the main casting when it let go and is not repairable. So it's become the largest paperweight in the collection.
I recently tried out the services of the boutique analogue film process lab Fotovramke in Kyiv. They processed two films from the Braun Paxette and I added a few images to that camera's gallery, but here's one anyway, taken in January 2020.
With everything that's going on in the world, it's time for a little colour, taken during one of my permitted exercise excursions near Percherska Metro station, using the ancient Paragon 500mm lens creates a viewpoint not normally seen.
Still alive, but with little to report. Three cameras have films in, but I am locked down without a darkroom to use...
A bit of a change this month. Amongst the myriad bits of old photographica that I have acquired are many negatives. This image of the Reichtag in Berlin was taken around 1946 by a late relative who was part of the occupying forces. The Reichtag was in the British sector. Already damaged by fire before the start of World War 2, it was well and truly ravaged by the time this image was taken in 1946. I've long wanted an excuse to publish it, but haven't been able to definitively identify which of the various family cameras was used for this image, but it was possibly the Ansco No.3 VP.
It's not possible to photograph the Reichtag from this position today, as you'd be in the middle of a hedge.
Turn right and walk a few metres from the position above and you will be in this position for the Brandenburg gate, again taken in 1946 possibly with the Ansco. Apart from the 120 roll film 6 x 9cm format, the image has been taken at waist level, the two pedestrians' eyes are obviously above the viewpoint. The Ansco only has a waist level finder. The original is clear enough to read the sign on the pillar that reads "You are now leaving the British Sector". The gate is liberally spattered with allied bomb shrapnel damage, small arms fire holes, heavy gauge machine gun impacts as well as the large shell hole near the sculpture near the top. The sculpture of Viktoria is blown to pieces, and slumped over her chariot. Later the Berlin wall would sweep in front of the gate making this view impossible for another few decades, the gate itself being in East Berlin. The wall finally fell in November 1989.
Our Zeiss Icarette dating from 1931, before any of the above had happened, was taken to the exact same spot as above to record the scene as it was in 2012. The pillars still bear the scars in the form of the uneven colouration, even though the damage has been repaired.
So that's my excuse for publishing the two interesting old family negatives above.
An image gallery for the Leica III has been added too. As I don't have an appropriate lens for this camera, it generally borrows the lens from the Leica II, but for this gallery I elected to put a Jupiter lens on, borrowed from a Zorki 4K. As the subject material was mostly around Ukraine, it seems fair enough.
Currently the Paxette, Brownie F and Zeiss Ikonta 520 are loaded.
A handful of results for the Zorki 1 have been added. Sadly it has a shutter issue, the second curtain is tripping too early, and is sluggish allowing the first curtain to run away, the result is seen here, with the very dark edge on the left side. I may be possible to sort it out, but the camera is still original and I think I would prefer to keep it that way, rather than renew the curtains in this case. All the same, dark edge included, I quite like this image., and it was the very last one on the roll. Isn't it always the way.
The Leica III has been returned to the cabinet after finishing it's outing, but as the camera was using a coated lens, it was shooting colour reversal in this case. As a general rule, if the lens is coated, I shoot colour, if not - black and white but it's certainly not a hard and fast rule. Still awaiting the processed films back, as I can't process E6 here.
I also adopted a Kodak Brownie Model F this month.
Right now, only the Icarette has a film in it.
The Thornton Pickard Reflex continues to be favoured despite only having two vaguely serviceable plate holders, as betrayed by those four scratches running through the sky. It was a long drive, over 450 mile round trip to expose just two plates on a day when this Avro Lancaster was having one of it's running days. The other plate was fogged. NX611 is a Lancaster B Mk VII, dating from April 1945, which means the Thornton Pickard Reflex was already twenty years old when this Lancaster was shiny and new.
Although NX611 is not airworthy, it is regularly moved under it's own power and as each item comes up for overhaul it is completed to airworthy condition, such that one day it can leave the ground once again. It's a spectacular achievement and in a very period setting, please visit the LAHC for more information and support their efforts.
Two recent arrivals have joined the museum after clearing the workshop, another Russian Leica copy - a Zorki 1 and a development of the same camera, a Zenit 3M.
Apart from the Thornton Pickard, other cameras currently loaded are the Leica III, Zorki 1 and Zeiss Icarette.
Entering the workshop this month is this particularly snotty Robot II, dating from the immediate post war period. It's almost identical to pre war models, presumably making use of the same tooling. The lens serial dates it to 1944, although the camera was certainly made later.
This poor thing is in atrocious condition, corroded throughout and the lens heavily fungus etched. The man made covering can't be saved. It is however making weak attempts to work, and a film found inside it produced some very weak images that showed it was working into the 1970s. It did have both N and T type film canisters within it.
It's going to require an extensive effort to make it presentable, even the badge has corroded to powder on the back. I have published the image here to make it public and so force myself to complete the job. The end result will be little use other than a paperweight though, as the Schneider Kreuznach Xenon lens is severely fungus etched, the surface looking like the sea under a microscope. Quality control at Schneider Kreuznach in 1943/44 was a bit lacking too, as there are two objective lens bubbles inside the f/11 arc.
Well I am happy to report that the Spotmatic survived its winter trip better than I did. It didn't even make it out of the camera case in South Africa, which was a shame as I had hoped to catch some wildlife with it. Instead it went to Ukraine and into the 10km exclusion zone around the Chernobyl nuclear reactor plant in late April 2019. I exposed two rolls of ancient HP5 in the Spotmatic and it gave 70 images. I thinned these down for the gallery, but there are a fair few of Pripyat, the abandoned city in the shadow of Chernobyl. The Thornton Pickard had another image added to its gallery this month, but the one below was made with the Spotmatic near Kyiv, Ukraine.
On 30th December, Keith was seriously injured 200km North of George in South Africa. He suffered multiple rib fractures and a broken clavicle, then developed pneumonia as a result of chest injuries. Although on the mend, it seems unlikely that there will be any updates to the LICM for some time. Keith reports that the LICM Pentax Spotmatic which was with him as the time, escaped damage - but sadly didn't get a chance to be used either.
A full year after new shutter curtains were made for the Thornton Pickard Reflex Special a handful of negatives were exposed in it to test the shutter. The film used was the last of some Ilford FP4 quarter plate cut film, that has lived in the fridge since 1984, one of which is at left. The remainder were on Efke stock. Efke are now sadly defunct.
You can see the camera being rebuilt in Project 6.
The Parvola, rebuilt earlier this year, has had an image gallery started for it now.
The Ensign Focal Plane Reflex has had it's image gallery updated after several years on the shelf.
Further contemporary images from Grandad's DRP have been added to its image gallery too.
This is the sad looking Ihagee Parvola as it arrived last month. A great deal of effort was expended on it as it needed a lot more attention than first thought. The Compur shutter was taken apart completely, for when I got the front off - I have never seen so much debris inside a still working shutter. Quite amazing it was still releasing at all. All the leaves needed taking out and cleaning and both cocking and release pivots were bent. The tatty plating has been left though. There's a little bit of blooming on the lens front element which isn't harmful and the lens is in good order. The leather had been painted at some point to disguise the poor state and the camera had clearly got quite wet at some point. Both of which meant the leather covering needed to be replaced. The approach used for this Parvola was to undo the results of neglect and damage and retain natural wear, then return functionality. The Parvola was also used to try out a new method of making leather impression stamps for the Ihagee logos, this is documented in Project 7 on the workshop pages.
The camera has now has its own entry on the museum pages after it's restoration/conservation treatment. It is currently loaded with a roll of our diminishing stock of 127 roll film, so let's hope all is well with it.
One of our long term residents, an Ensign Focal Plane Roll Film Reflex (crikey, that's a mouthful - no wonder they renamed it the Speed Reflex), recently went into the workshop (yet again!) as we found a donor to supply all the parts it needed. Viewing hood springs, correct shutter selector catch, undamaged top housing with better leather in the hatch, neater lens cover, a handful of screws and a usable carrying case. Other than that the donor's innards had all but rusted away.
This contemporary image from 1938 shows one Trevor Edmund Thomas, on the shore at Weston-Super-mare. At this time Trevor was the owner of our Graflex 1A. We know this as he had written both his name and two addresses in the back of the camera. Although faint and confused with scratches and wear, a bit of research in the census found a name of a surviving relative, to whom we wrote in May 2018. The fabulous outcome is this image. The lady I wrote to is Dorothy, the little girl in this picture. Behind her is her father, Trevor and we also see his wife Olive and their son Arthur. It would appear that this image is reunited with the camera that took it almost eighty years to the day.
Very much of the era, it's a very warm summer day, sunny but hazy looking roughly easterly. Trevor is dressed in a full suit and waistcoat, a tie and neatly folded handkerchief. Wherever possible we like to show images known to have been taken by each camera, contemporary ones especially so. So I'd like to express my thanks to everyone who helped resolve the evidence trail that lead to the address, and Dorothy and her daughter Vanessa for finding and allowing me to publish this picture.
For anyone totally fed up with the e-mails about data protection etc etc. You'll be pleased to know I don't keep anything! Unless you send me an e-mail, in which case I store those until I get bored of them in my in box. I'd love to give you a time scale, but rest assured, my boredom threshold is pretty low. Also I don't have the technical competencies to deal with all that cookie malarkey, so have had to discontinue the Google adverts altogether, otherwise those nasty Google people will try to track you and send you lots of adverts about things you've already looked for and bought last week.
Additional images added to the image gallery for the 1934 Kodak retina model 117.
In November 2017 the old Kodak Retina, now 83 years old and, you might think, overdue for retirement - was despatched on what would turn out to be almost a world tour. The camera was taken from the display case, given the briefest of checks entailing a quick look for holed bellows and a visual test of the shutter, two films were grabbed from the fridge and off it went. In the next 6 months it was subjected to temperature ranges of -10 to +33c. Altitudes up to 11,000ft and about 30 airport x-rays. Of the 70 frames exposed, 58 are usable. The exposures mixed on those two films ranged from night time long exposures to insane cold, high altitude and sun so bright it made your eyes hurt. Both films were then developed together in the same tank in multi-shot ID11. What could possibly go wrong!
Workshop activity is continuing with the Ensign Focal Plane Reflex having a fairly extensive overhaul, the Thornton Pickard Ruby reflex needs new velvet light seals in the plate carrier and I have been collecting together the materials and information for a total rebuild of an Ihagee Parvola wreck, this will entail new leather work and pressing logos into the covering when finished. I am developing a new method to replace the way I have been doing it for many years, documented in Project 1. This will be written up in due course and added to the workshop pages.
Yes, still here! In terms of vintage photography I have nothing to report. The Nikon FE is out and about as is the Kodak Retina 117, but nothing to add to their pages.
And finally after 20 years, I decided to stop hiding and put up an "about" page, so those of an inquisitive disposition can find out about the author.
The view from my mountain hideaway as the sun went down on February 28th 2018, so just about okay for inclusion. This was taken with the trusty and quite battered Pentax K-X. I also used the Kodak Retina 117 for a similar shot, but that will have to wait.
The mountains are the Trans Ala tau, but I don't think anyone will be able to track me down from this angle.
But here's some weird, very obscurely related photography related news. Okay, that is pushing it somewhat, but I am struggling to find anything to write! Amongst my innumerable interests, I occasionally like to play with drawing or painting, as well as a bit of writing.
I recently completed a book entitled OF OUR OWN DEMISE and wanted to do the cover illustration. Now the subject of the book has nothing to do with photography, so I will not go into it here. But I elected to draw the image as a negative, exactly as you see here. As a creator, when I draw normally, I can see the progress that my efforts are taking, adjusting and modifying as I go. But I decided for this, the creator would have control but the final outcome couldn't be entirely known.
"The creator does not have total dominion, but absolute interest."
The final outcome would not be known until the image was "processed", in this case digitally inverted. It was interesting as there's a strong parallel with taking a photograph and seeing the film for the first time as it exits the developing tank. I was very strict with myself, I drew it once, when I was happy with the negative, I had it scanned and then flipped the negative in good old "Photoshop". The result was pretty much as I wanted, but seeing it for the first time was a joy normally denied me.
If you are curious as to the finished image, click here!
November was very busy with the move. Life will be very much different now, but I will attempt to look after the website from time to time. I decided to add a page that explains why, what and how "Rise and Fall" lens movements were used. So many folding cameras were fitted with the feature from the 1900s - I thought it might be useful to someone.
Follow this link to find the page.
And please visitors, do me a favour and take a look around the site, visit a few more pages. Whilst the majority of visits come from search engines, this somewhat perversely damages the figures. Visitors who type in a search, visit a page, find out what he or she wants then leaves is recorded as a dis-satisfied customer so far as Google is concerned, as they seem to think that "engagement" is vitally important, i.e.. - how deep into a web site you go. Hence the number of sites festooned with "click bait". So sites like this that give you information free of charge and without making you "go round the houses" to get it, are penalized with high "bounce rates". So please, do me a favour, and delve in a little deeper!
What's new indeed, pretty much everything. New clothes. New home. New Country. New language. New weather. Gave up my job after 30 years in the same company.
Buy hey, if you're going to have a shake up, have a good one. So I am currently living in Almaty, Kazakhstan. Righto, enough about me.
My place of employment for over 30 years. Draper Tools Ltd, from Early 1987 until October 2017. I enjoyed my time there, felt valued and I think I must have worked with almost everyone to a greater or lesser degree during my stay. Although Draper's were fabulous and everyone from the Chairman, John Draper, down were sorry to see me go, I think 30 years is enough.
in 1998 this photograph was taken with the collection's Williamson WF117A aerial camera on one of a very few outings for it. This was taken by a friend using the Williamson from the right hand seat of C172 G-BHCC as we passed by back in 1998.
The head Office building stands out well in the town of Chandler's Ford. It was also well positioned as a good marker to start the run in to Right Base leg for runway 20 at Southampton Airport, back in the days I could fly in there. You'd never see a Cessna 172 in there today, it's wall to wall Flybe Bombardier Q400s.
Cameras wise, I'd long been cooking up ideas about making new shutter blinds, and have put quite a few in over the years. Some years back I bought some new shutter cloth from Micro Tools, but was a bit dismayed with it, as it was far too thick for the Ensign Speed reflex that it was intended for. But that's all I could get so I used it and adapted the camera to take into account the extra bulk of the cloth. Earlier this year I went to use the Ensign again but it was dead. Accordingly I thought it was time to take it all to pieces and make my own cloth to the correct thickness, as I had hatched a plan to make my own cloth and an experiment suggested I was on the right track. I had hoped the original Micro Tools cloth had degraded as it was well over a decade old. Alas no, when I stripped the camera the problem was easily resolved, so I just elected to fix the issue and move on. But I felt cheated! I had this idea in my head, and I simply had to give it a go. So I went on a hunt for a camera with a nice big cloth shutter that was in need of replacement. It didn't take long. It was advertised as a Butcher's Reflex camera. It was unmarked in any way, but with a Butcher's Aldis Anastigmat. Butcher's were notorious in not marking their cameras, as they had a history of just importing them "off the shelf" from Germany prior to the First World War and then having Houghtons Ltd. in London make them when the German supply kind of became inconvenient. So unmarked cameras from Butcher's are not at all uncommon. It didn't quite look right though. But no matter, the camera was just what I wanted, externally and cosmetically is was fine as it was, but the shutter curtains were totally ruined. Perfect.
So I put my long awaited idea to make new shutter curtain material into action, and am pleased with the outcome. I wanted to make my own as I needed control over the thickness of the finished material and I had rejected the methods I that others have posted online as being unsuitable. One method I've seen involves painting cloth with acrylic paint on one side, but it doesn't produce the soft pliable low drag result of the original material.
Anyway, the method I cooked up can be seen in Project 6, and the restored camera, which actually turned out to be a Quarter Plate, Thornton Pickard, Junior Special Ruby Reflex can be seen in the museum pages.
Sadly with all the changes of recent weeks, any thoughts of using the cameras is on hold for a few months.
Well no, that's not entirely true. I did just manage to scurry off to get a film processed that had been languishing in the FED 3 for a while. That's actually one of the things I like about chemical photography, the fact that memories are locked away, latent - as Fox Talbot would have said, awaiting rediscovery upon processing. This instant digital gratification has its place, but I rather do like the wait, and birth of an image. The investment of hope, experience and time. Anyway, I will add a few more images to the FED 3 gallery.
One of my occasional experiments with Autochrome-esque images.
The camera I chose for this attempt was the Ensign Selfix 220, a 1950s era 120 roll film camera.
Mainly because I hadn't got around to publishing any images with it. Now the Selfix is nothing special, with a fairly average lens and self energizing shutter, with a harsh action, making camera shake a very real likelihood. My attempts to make colour images with this camera, mimic those of the earliest attempts, that is three separate exposures through coloured filters, first Red, then Green and then Blue are made on black and white film, then processed as usual. Originally, these were then made into positives, then each image was projected via it's own projector through the same filter to be coincident on a screen. This later part is done digitally here, by scanning each negative and then putting it in the appropriate channel in Photoshop - but it's much the same process, just easier as it avoids having to get three projectors working together.
The camera needs to be tripod mounted, and the filters I used were fairly dense needing a three stop increase in exposure. The camera had a bit of an issue with frame spacing, the result is the colour bands down the sides of the image, which enhances it no end.
The subject is the Hydrangea in my garden, which cannot make a decision as to be blue or pink, so invariably does a half and half.
The first film, a Foma 100, went through the Reflex Korelle and has been processed. All told I am quite pleased that the old Korelle got to celebrate it's 80th birthday with a film. The B model is far from the best of the Korelles, but I enjoyed getting it to work and I am reasonably pleased with the results from the first attempt. The one at left is a small part of the very first picture from the first roll from the rejuvenated Korelle B. The only issue may be the first curtain out accelerating the second by a fraction, though this is hard to tell, so I will wait and see what the faster shutter speeds show up, also one film roller is a little sticky which has made some tiny scratches on the emulsion, but this ought to be easily cured. The camera itself is completely light tight without a hint of fogging or streaking, which makes a very pleasant change for once. A few more frames from this first film can be seen in the camera's image gallery,
Grandad's old DRP was given what will be it's final outing. 90 years after Gramps bought it, his daughter was photographed by his Grandson with the 1927 DRP.
The FED 3 went on some travels to Kazakhstan, no results back from that trip as yet though. Recently I was seduced by Reflex Korelle. Every collector wants one of these, and they are fairly common. The unusual one is the Reflex Korelle B, the rarer though cut price simplified version that no one wants, so that is the one I acquired for the camera equivalent of a donkey sanctuary. It's been through the usual deep clean and had a new shutter made for it. It currently has a test film in it, but that's not finished yet. However the restoration can be seen in the workshop pages as project 5.
Sorry, the adverts have to go on again, It looks like I will be unemployed soon, so I cannot afford to fund the website anymore. Hopefully the adverts will cover the cost of the hosting. Apologies, I hate putting them on.
Not much of note going on that's visible. In the background I have been sourcing backing paper for 118, 122, 124 roll films. This will be re-spooled with film I have acquired from Ilford. This should enable me to start sorting out some galleries for some of the more awkward sized cameras. The next problem is processing as I don't have any appropriately sized spirals, but I've got this far so I'm not giving in yet.
A fairly momentous beginning to the year for entirely non camera related reasons but on the camera front, a handful of images were added for the rebuilt FED 3 which has proved to be an absolute gem. Although the test film wasn't exactly visually stunning, the experience of using the FED was a delight. Happy New Year to all.
A very attractive FED 3 donated from Russia has been resident in the workshop for some weeks, it has now been restored and joins the collection pages, along with a humble Lomo, Smena Symbol and a No.3 Folding Pocket Kodak dating from around 1907.
The camera that takes the credit for inspiring my interest in old cameras was given an outing earlier this month. Having sat in the display case for some time unused, it required a quick clean and check over, but all seemed in order. It was taken to this old saw mill in late evening, with just one plate loaded.
Yikes, is it a year since I used any of the cameras? Sadly yes. The cost of replacing the computer to author the web site totally consumed the budget for film and chemicals. However we have just restored the Ensign Midget, it waited a mere 32 years before it got the chance. It was promptly sent to Siberia.
||One of the images from the Siberian trip, taken near Omsk in August 2016. The Ensign Midget performed rather better than I'd hoped, returning six out of six images for the one film I had wound for it. The others can be seen here,
Nestling in the back of the cupboard was an old box of Ilford ID11 powder developer, reputedly this has an almost limitless shelf life. This box was the wrong side of 20 years old, so in an extreme product test. I mixed it up and processed the rolls from the Exakta VP. Mixed to stock then used as 1:3 one shot developer, it was fine! Thumbs up for Ilford ID11. So here's one one image from the Exakta VP-B, depicting Bristol Blenheim returning to RAF Bicester for the first time in 70 years.
||Whilst comparing the Exakta VP to recent SLRs reveals many shortcomings, considering the era from which the Exakta hails, you have to be impressed, It's easy to use, the lever advance sweeps the next frame in reasonably quickly and the controls are easily set. Fine focussing is a little tricky, but gets the desired result. A fine instrument of the day, a good working example is worth persevering with.
Good new for the visitors, bad news for me. After three attempts to buy old MacIntosh computers I got ripped off by some idiot, who ran off with the money - fortunately, Ebay refunded me most of the money. Another machine was totally rubbish, it wasn't even worth the postage to send back, so that went to the skip, and finally the one I am writing this on. Then I had to fork out for newer software, ouch. So the Museum funds are relying on loans. I can only hope that I get some income from the Google adverts soon, although in light of recent performance this looks unlikely. So sadly there is no money for film and processing for some time. The last four rolls of 127 roll film went into the Exakta VP a few weeks back, sadly they remain unprocessed for now. However I did scrape up enough to process two rolls from the Varex IIa, it was despatched to Uzbekistan back in April where it was nearly lost, as it was impounded at Uzbek customs along with the VP as they contravened their export rules. The rule is supposed to protect Uzbek antiques from being taken out, but the border officials apply it to old cameras too. Luckily the cameras were being escorted by a UN negotiator, and they won the day. Phew. Some results from the two rolls of film that went through it are on the gallery for it,
The Kodak I restored FOC for the chap in Northern Ireland has now been returned to him. The deal was I got to keep it for three weeks to sit on my shelf. Whilst it was resident I managed to get one image from it. As it was roughly 1912, I managed to find this period aeroplane at Bicester. It's a reasonably convincing replica of a BE2c, modified from Tiger Moth airframe.
Another year rolls by. The end of 2014 saw two new arrivals,
both Exaktas. One a Varex II b and one VP, these are currently workshop
residents, so aren't on the web site yet. The Varex looks to be a straightforward
cleaning task, whilst the VP is likely to be more involved, possibly requiring new
curtains, but the whole thing is jammed currently so hard to tell. I have
added some results for the Praktica
Super TL. I never thought Prakticas got the praise they deserved,
the Super TL performed rather well and in the hands of a decent photographer,
which patently I am not, I imagine it would be possible to get some fairly
spectacular results. Anyway, here's a taster, happy New Year.
||Stop Press! The Exakta
II b and Exakta VP have both
passed through the workshop successfully and now have entries on the
web site. The VP was a bit of a challenge but appears to be behaving.
This was a repair and conservation job, all the original parts have
been used, the shutter curtain tapes had snapped and wrapped themselves
around the internals. They needed washing and ironing to get them
flat again, before putting back in slightly shorter than before. Getting
the shutter set up again was a bit awkward, but a slither of paper
around the roller bulked things up enough to keep the curtains running
about right. Fingers well and truly crossed!
A recent planned outing for the Sanderson
revealed the Dial Set Compur had gummed up. It had never been opened up
in the 30 years it's been a resident, so it was a bit overdue. Cleaning
sorted it out, but whilst I was in there, I did a cut-away picture, you
can view the full size by clicking the image, This Compur, mounting an
f4.5 Zeiss Tessar, was originally fitted to a Contessa Nettel, whose serial
the Compur is proudly displaying. Presumably that camera was broken up
at some point and it's shutter/lens combination used to update the Sanderson.
In turn, when the Sanderson wound up at the LICM, I rebuilt it with an
original Bausch and Lomb Unicum, keeping this Dial Set Compur and Tessar
combination as an additional setup.
I've added some images for the Nikon
FE taken in Kyrgyzstan, as mentioned previously, here's a taster...
Whist the image on the right was made with the Rollei
Well, I have been rather avoiding the website in recent
months, concentrating on motorcycle restoration rather than cameras. In
April I took a couple of the cameras to Kyrgyzstan again, the Nikon
FE and the Rollei 35. The most recent
outing was for the Ansco No.3, very much
a humble member of the collection, this was the best I could get out of
In 1861 the Scottish theoretical physicist James Clerk
Maxwell whose most celebrated work concerns magnetism, electricity and
electromagnetic fields, created the first colour photograph. He achieved
this by making three exposures of a tartan ribbon, each through a different
coloured filter - red, blue and yellow. The resulting negatives were then
made into positives, and all three were then projected through their respective
filters onto a common screen. This additive process results in a colour
image on the screen. As a homage to this event, I decided to have a go myself. I elected to use the common
additive colours used today, known as RGB - or Red, Green and Blue. I
used our 1908 Sanderson quarter plate camera
for the experiment. This required, a complete service
before it decided to play nicely, as the Unicum shutter had decided to
jam. So I set up a suitable still life with only natural light from one
side, a mirror to shine some light through the back of the glasses
and made my three exposures. I compensated about three stops for the rather
dark filters I found. These were then processed in a suitably vintage
tank, and the developer was left in too long deliberately, to punch up
the contrast and was developed on the warm side. Just to really give it
the aged look, the wash was freezing cold to really mess up the emulsion.
As I don't have one projector that takes quarter plate, let alone three
identical ones, the negatives were projected onto paper, photographed
then combined on the computer to finish the process. This is the result.
Maxwell's original can be found easily enough online.
On the camera front, we have been very busy in
the workshop, acquiring a 1915 Graflex 1A
in decidedly rotten condition as a challenge, for my 50th birthday. After
many hours work, it has been returned to working order. We are also resurrecting
a Ensignette and a Leica
III is waiting its turn. Three further images have been added for
the 1902 Sanderson, here's one of them.
